| Model |
SF-FP80 |
| Size |
2000x1000x80mm |
| Panel weight |
32kg |
| Panel volume of liquid |
2.20 liters |
| Test pressure |
20 bar |
| Max operating pressure |
10 bar |
| Pressure loss across panel |
1m bar |
| Absorption level |
95% |
| Thermal emission level |
3% |
| UV absorbance level |
97% |
| CO Displacement |
383kg CO (per panel per annum) |
| Absorber plate |
Copper |
| Internal pipework |
Copper |
| Glass |
Low ironed tempered safety |
| Glass transmission |
91% |
| Insulation |
Rock wool |
| Base thickness |
50mm |
| Side thickness |
20mm |
| High limit temperature |
230°C |
| Casing |
Aluminum |
| Back plate |
Galvanized steel |
| Riser to absorber plate fixing |
Ultrasonic weld |
| Type of mounting |
Slope roof and flat roof |
| Gross area |
2.00 sqm |
| Aperture-Net Area |
1.80 sqm |
